| Display Type |
LCD with Backlight |
| Display Configuration |
3 Rows of 4 Digits, 1 Row of 7 ½ Digits |
| Electrical Connection |
3Ø – 3W, 3Ø – 4W, 2Ø – 3W, 1Ø – 2W |
| Type of Output |
Pulse Output |
| Features |
Password Protection, Energy (Active / Reactive / Apparent) |
| Communication Protocol |
RS485 and MODBUS RTU |
| CT Primary |
1 / 5A to 10kA (Programmable for Any Value) |
| CT Secondary |
1 / 5A (Programmable) |
| PT Primary |
100V to 10kV (Programmable for Any Value) |
| PT Secondary |
100V to 500V AC (L – L) (Programmable for Any Value) |
| Rated Input Current |
Nominal 5A AC (Min – 11mA Max – 6A) |
| Supply Voltage |
100 to 240V AC (-15% to +12%) (45/65Hz) |
| Size |
96 x 96mm |
| Mounting Type |
Panel Mount |
| Certification |
CE, UL Listed |
